Heating Controls



Smart heating

Use Herschel heating controls to manage your home or office heating from wherever you are, whichever rooms and schedules you choose, and ensure a warm and cosy space to return to.

Our Herschel iQ control system offers an App-enabled range of options to ensure you manage optimum comfort levels and maximise energy efficiency.

All Herschel iQ controls will ensure you are fully compliant with European Energy Saving legislation (Lot 20).

Control Features

Check out the features of our iQ heating controls using our interactive picture below.

Which Control is best for me?

Click + to show the features of each iQ control below to see how each can suit your needs.

App-enabled Solutions

These controllers work stand-alone or over the internet via the iQ App.

MD1 Wired Thermostat – best for new builds / renovations and commercial applications

Use one MD1 per room / zone and wire all heaters within the room onto the same circuit.

MD1 is wired to the mains electricity supply & requires recessing into the wall.

This is the best option for new builds or renovations where cabling runs can be hidden in walls / ceilings.

Can become App-enabled by adding the Herschel iQ hub (optional).

T1 Wireless Thermostat Pack – versatile solution which minimises cabling / disruption

Use one T1 per room / zone and one R1 per heater. Each R1 requires mains electricity supply.

Wirelessly pair each R1 to the T1.

The T1 can be located anywhere in the room and is battery operated so does not require mains supply. Can be surface mounted to the wall or placed on a shelf. A great retrofit option minimising disruption to walls / ceilings because R1 can be located close to heater.

Can become App-enabled by adding the Herschel iQ hub (optional).

R1 + iQ Hub – Slick App only control

Wire all heaters on the same circuit to the R1 (up to 2kW per R1). Requires a minimum of one R1 per room / zone.

Program and control the heaters using the APP only.

Note: the R1 will sense the room temperature which will be displayed on the APP. Must be used in conjunction with the iQ Hub.

This is a good option where heaters are ceiling mounted and cabling can be run in the ceiling void with the R1 positioned on the ceiling or wall.



Get the Herschel iQ App here:

Non App-enabled Solutions

WH1 Central Controller

Our WH1 Controller system offers a local centralised control solution. Control all your heaters in the property from one colour touchscreen unit. Heaters are controlled wirelessly without the need for wifi. Choose this option if you want the benefits of centralised control but do not need to control remotely or do not have wifi.

Each R1 receiver pairs with the WH1 and you can program each R1 to run its own 7 day program or run in Away or Comfort modes.

Up to 36 R1s can be added to a single WH1 and allocated to 6 different zones (6 R1s per zone).

Note: The WH1 system is unable to be app-enabled.

NOTE: Herschel iQ will only work with Herschel heaters.

Choose from our full range of iQ Controls below.

• Herschel iQ Hub



  1 Warranty

  1 Sizes




  £77.00 inc. VAT

  Key Features:

  • Enables App control of Herschel heaters
  • Connects to router
  • Control iQ Devices from one App
  • Up to 8 separate Herschel iQ devices
  • Room by room control
  • Lot 20 energy saving features

  View Range

• Herschel iQ MD1 Wired Thermostat



  1 Warranty

  1 Sizes




  £70.00 inc. VAT

  Key Features:

  • 16 Amp wired thermostat
  • 7 x 1 day programmable
  • Open window detection
  • Temp control up to 45℃
  • Keypad locking feature
  • Optional internet control via App & Hub
  • Control upto 3.6kW Herschel heaters

  View Range

• Herschel iQ T1 Wireless Thermostat Pack



  1 yr Warranty

  1 Sizes




  Rated 4.67 out of 5

  £69.00 inc. VAT

  Key Features:

  • Energy-saving (Lot 20) features
  • App-enabled with iQ Hub
  • Battery operated T1, digital display
  • 7 x 1 day programmable
  • Open window & adaptive start
  • Pack controls upto 2kW Herschel heaters
  • Includes one T1 + one R1

  View Range

• Herschel iQ R1 Receiver



  1 yr Warranty

  1 Sizes




  £38.00 inc. VAT

  Key Features:

  • Wireless receiver unit
  • Use with T1 thermostat
  • Can be used directly with Hub
  • 1 hour boost function
  • Open window technology
  • 10 Amp load at 230 volts
  • In-built temperature sensor

  View Range

• Herschel iQ WH1 Central Control Unit



  1 yr Warranty

  1 Sizes




  £179.00 inc. VAT

  Key Features:

  • Whole house heating control
  • Control up to 6 zones
  • Up to 36 R1 receivers
  • LCH touch screen
  • Suitable for homes & commercial
  • Simple flexible control

  View Range
