Inspire – Mirror Infrared Heater
What size panel do I need?use our
|Watts||Panel size cm||Heated area|
|250||60 x 30||3 - 5 m2|
|350||90 x 30||4 - 7 m2|
|420||60 x 60||5 - 8 m2|
|550||80 x 60||7 - 12 m2|
|750||90 x 70||11 - 18 m2|
|900||100 x 80||13 - 22 m2|
|1250L||160 x 60 (for dwarf walls)||17 - 29 m2|
Heated areas change considerably according to building age, window area and other factors.
Be sure to use our wattage estimator or ask us for help.
Herschel infrared mirror heater panels are an ideal addition to your bathroom, hallway, or to the reception area or lobby of a corporate building, combining sophisticated design with optimum safety and energy efficiency.
All units are made with Mirror Safety Glass and manufactured in Germany from the highest quality materials and are guaranteed for 10 years. Infrared mirror heater panels can be placed in humid areas such as bathrooms without any condensation forming on the glass, whilst also chasing away the causes of moisture that other heater types actually encourage (hot air moving over a cold surface).
Due to the infrared heating process, the mirrors heat up objects in the room rather than the air. This helps keep bathroom walls and fittings warm, dry and free of mould.
Available in seven different sizes and power outputs from 250 – 1250 Watts to suit every requirement, Herschel Inspire infrared mirror heaters operate at a fraction of the cost of traditional heating, but offer higher thermal comfort levels.
Inspire panels are designed for professional installation only and do not have any inbuilt receivers. They must be controlled with our Herschel IQ controllers and there are a number of options (sold separately) to choose between. The panels are directly wired either to our MD1 hard wired thermostat or to our R1 receiver. Full APP control is available with the purchase of our IQ hub. Select your thermostat options below.
Click here to download the Data Sheet.
Click here to download Installation & Operating Instructions.
The heated areas are a guide only and assume a medium to well insulated space with an average floor to ceiling height of 2.40M. If room heights are greater or there are other building factors to consider then please use our Calculate Your Requirements page, Contact Herschel, or contact your dealer directly so that a more detailed assessment can be carried out.
Field of application: Direct Heating
Surface: ESG Mirror Safety Glass
Rear-panel: Sheet steel, powder coated, with mounting points
Surface temperature: 85 – 95°C
Cable: 3m power cable
Voltage: 230V 50hz
Protection Class: IP54
Installation: Wall mounted.
Quality & Safety
TÜV GS Certification (by TÜV Rheinland, Germany)
EMC Certification (by TÜV Rheinland, Germany)
ErP Regulation (EU) 2015/1188 and Supplement (EU) 2016/2282 (Lot 20).Valid from 1 January 2018 when used with Herschel iQ
Made in Germany, typically 1 – 2 week delivery
Guarantee: 120 months
Control Options (Required)
Herschel iQ MD1 Wired Thermostat
Herschel iQ T1 Wireless Thermostat Pack
Herschel iQ Hub
Herschel iQ WH1 Central Control Unit
